AFB-250

  • BSRF

  • 제조국 : Made in France

DUAL RX ANTENNA FIBER BOX AFB-250

기능 및 특성

  • Dual Rx Antenna Fiber Box
  • AFB-250 is designed to modulate radio signals from two receiving antenna to one optical Neutrik Duo APC output. Any passive or active antenna can be plugged in as it provides DC feed. DC feed are protected from short-circuits. A RF peak led indicate if RF field is too strong. A built-in 10dB RF attenuator can be activated on start up of device. With its rugged housing and 12V on XLR4 power, it is designed for location or live market.

Technical Data

  • Bandwidth : 470Mhz–800Mhz
  • RF inputs : 2xBNC 50 ohms
  • DC feed : 12V/200mA
  • Input attenuator : 0/-10dB
  • Optical output : OpticalCon Duo,1310nm, monomode, APC
  • Current : 500 mA
  • with one active antenna : 600 mA
  • with two active antennas : 750 mA
  • Supply : XLR4, 12W max
  • Dimensions : 155 x 180 x 70 mm
  • Weight : 1,3 Kg
